12# ClipFoam™ Tape

MATERIAL/SUBSTRATE:
Crosslinked Polyethylene Foam
DENSITY:
12 lb/ft3
LINER:
Blue PP
ADHESION TO STEEL, AIR SIDE [PSTC-101 MOD]:
86 oz/in
ADHESION TO STEEL, LINER SIDE [PSTC-101 MOD ]:
94 oz/in
TENSILE STRENGTH (GLASS/GLASS):
121.83 psi
SHEAR STRENGTH (GLASS/GLASS):
90.50 psi
SHEAR STRENGTH (ALUMINUM/GLASS):
85.14 psi
SERVICE TEMPERATURE:
-30°F to 220°F
VOLUME RESISTIVITY, 500 VOLTS @ 85°C , 85% RH:
Exceeds 4.8e+12 ohm*cm
CELL STRUCTURE:
Closed Cell

Product Overview

High performing mounting tape with very high bond LSE type supported adhesive.

Typical Applications:
• Seal against air, moisture, light and dust
• Bonding irregular surfaces, cushioning
• Insulates in thermal and sound deadening
• Bonds well to aluminum and glass in solar applications
• For use with molded and extruded plastics
• Shock and vibration absorbance, gap filling
• Extrusion applications
• Substrates including ABS, TPO, PE, PP, powder-coated paints and metals

Features & Benefits:
• Moderate tack
• Excellent shear strength and adhesion
• Excellent high and low temperature performance
• Conformable
• Foam+PET laminate reduces foam stretching and aids in bonding to extrusion substrates at relatively high speeds
• Minimal moisture absorption
• High density for high performance needs
• Foam die-cuts cleanly and easily
• Lends itself to die-cutting and kiss-cuts
