Features & Benefits:
Adhesive has excellent peel and shear values.
Inexpensive alternative to commercial grade neoprene, rubber and EPDM setting blocks
Acrylic adhesive gives great high and low temperature and weather resistance
PVC compound, can be recycled with sash components
Low/no skid
Typical Applications:
Livestock trailers (no skid), dock ramps, and aluminum dock vibration damping
Aluminum dock decking spacer tape
Test Methods | PSTC-1, ASTM D2240, SYNTAC TM, ASTM D412 |
---|---|
Durometer / Hardness (Shore A) | 75 |
Adhesion / Peel Value | 6.25 lb/in |
Adhesion Range | 5-9.99 lb/in |
Minimum Temperature Range | -20°F |
Maximum Temperature Range | 200°F |
Tensile Strength | 250 lb/in2 |
Loop Tack | 109 oz/in |
Durometer Shore A (Range) | 60+ |
Environmental and Chemical Properties | Acid Resistance, Alcohol Resistance, Aldehydes Resistance, Detergent Solutions Resistance, Mineral Oil resistance, Reducing Agents resistance, Resistance to Aliphatic Hydrocarbon Fluids |
Loop Tack (Range) | 30+ oz/in |
Minimum Temperature (Range) | -15 - -29°F |
Tensile Strength (Range) | 250-499.99 lb/in2 |
